Digital Display Ammeter DC 0-100A Blue

SKU: 018-05-AM-100A-BL

$14.50 AUD, inc GST

More Views

Digital Display Ammeter DC 0-100A Blue
14.5 AUD

SKU: 018-05-AM-100A-BL

$14.50 AUD, inc GST
75 units ship in 15 to 20 days (delivered by Wed, 28th of Dec)
Shipping Offer
OR

Wide supply voltage operating range; 4.5-28VDC, current sample range is DC 0-100 Amps.

Features:

  • Measuring Range: DC 0-100A with the external 100A/75mV Shunt
  • Error: 1%
  • Display: 0.56" Blue LED Segment Display
  • Refresh Rate: 500mS
  • Power Supply: 4.5-28VDC
  • Current Consumption: 15mA
  • Operating Temperature: -10ºC to 65ºC
  • Dimensions: 48x29x36mm (LxWxD)
  • Hole Size: 46x27mm

Please note that the shunt negative wire and power supply wires must be isolated. Refer to the attached diagram.

Ammeters are susceptible to noise and are not suitable for use in cars or with DC-DC switching supplies. The distance between the panel meter and the shunt must be kept short to assist with stability.
